Mantis F6 Handheld 3D Scanner

Product Description

Mantis F6 Handheld 3D Scanner

The Mantis F6 is a compact 3D handheld scanner with an unparalleled operating range of 0.2m–4m that can produce high-quality 3D models in challenging lighting conditions and in hard-to-reach areas.

The F6 Smart is operated by Echo, an advanced and easy-to-use integrated software with high-end features such as:

• Advanced scanning modes with real time feedback
• Powerful 3D data editing tools
• Data quality for controlling distances and accuracies
• Flexible integration to 3rd party software based on Mantis Vision DLL or SDK
• Advanced meshing with full color projection
• Matching models from different scans
• Multiple interfaces: tablet/laptop/VR
• User interface: touch screen/ desktop

SYSTEM BENEFITS:

• IR light – enables work in any lighting conditions from complete darkness to day light
• Ergonomic rubberized handgrip
• No scene preparation – geometry is deciphered by the encoding
• 2 layer modes of operation: static and dynamic
• Accessibility to hidden places
• User friendly – professionals can operate the system after a short training
• Unique design and light weight – suitable for the harsh demands of the outside

Scan to CAD, Scan to Solidworks​
For usage in Solidworks or other CAD applications, the F6 handheld scanners offer a user-friendly workflow that transforms your industrial 3D scans into editable, precise, and professional standard CAD files.​

Mantis F6 SMART Specifications:

Hardware specifications

• Accuracy: 0.2% – 0.1% upon scanning distance
• XY point density: 5mrad
• Low noise level: less than 0.5mm@1meter
• Eye safety: Class 1
• Ambient lighting: From complete darkness to daylight
• Depth of field: 4.5 – 0.5m
• Linear field of view: HxW 510 x 670mm, closest range
• Linear field of view: HxW 4585 x 6070mm, furthest range
• Angular field of view: HxW 54 x 68°
• RGB camera resolution: 1.3MPix
• Video frame rate: 8fps
• Exposure time: 0.04 – 0.005 s
• Data acquisition speed: 640,000 points/s
• Dimensions, HxDxW: 32 x 12 x 4.5 cm
• Weight: 1kg
• Power consumption: Internal battery
• Calibration: No special equipment required
• Working temperature: –10° to +50° / 14’ to 122’F

Software specifications

• Multi-core processing: Yes
• Support OS: Windows 8/10
• Output formats: PTS, ASCII, PLY, E57, STL
• Interface: USB 2.0
